Radio – cellular
• 3GPP, release December 15 – 5G NR NonStandalone (NSA) option 3a, 3x
• 5G NR interface band n78 TD 3500 MHz (3300 MHz – 3800 MHz)
• Dual connectivity (EN-DC)
– 1 LTE + DC 5G (1+n78, 3+n78, 7+n78, 28+n78)
– 2 LTE + DC 5G (1+3+n78, 1+7+n78, 3+7+n78)
– 3 LTE + DC 5G (1+3+7+n78)
• Downlink (DL) 4x4 multiple input, multiple output (MIMO) and 256 QAM
• Uplink (UL) 1x1 single input, single output (SISO) and 64 QAM
• Supported carrier bandwidths
– 5G: 20 MHz, 40 MHz, 60 MHz, 80 MHz, 100 MHz
– 4G/LTE: 5 MHz, 10 MHz, 15 MHz, 20 MHz
• FDD B1 (2100 MHz), B3 (1800 MHz), B7 (2600 MHz), B28 (700 MHz), TDD B40 (2300 MHz)
• Extensive carrier aggregation between supported bands
Radio – Wi-Fi
• Dual-band concurrent IEEE 802.11b/g/n 3x3
2.4 GHz and 802.11ac 4x4 5 GHz
• Mesh topology with Nokia WiFi Beacon 3s
• Seamless roaming (IEEE 802.11k, 802.11v)
